APPLICATION

Application Warehouse, Manufacturing, Narrow Aisle

FEATURES

HYDRAULICS

Permanent magnet DC pump motor and chrome plated cylinder provide for smooth and efficient lifting.

ELECTRICAL

Water resistant connectors and shrouded wiring harness supply power reliably to components. System includes a key switch; emergency power disconnects and on-board dock for Easy Exchange Battery.

BRAKES

Electromechanical brake provides good stopping power when handle is upright or lowered beyond the operating range.

CONTROLS

Travel, lift, and lower functions are located in the ergonomic operator handle. All operator controls are accessible without having to lift one’s hand from the loop handle. The control head is designed to allow easy operation with either hand and includes a belly button reversing switch, dual butterfly travel controls, horn, battery discharge indicator and manual lowering control for quick and efficient operation. The low mounted tiller arm offers excellent operator comfort and minimum steering effort.

DUTY CYCLE

Revolutionary Easy Exchange Battery delivers up to 3 hours of operation and can be fully charged within 2.5 hours. Optional extra batteries can be purchased to extend run time or to serve as a reliable back-up.

FORKS 27” OAW x 45.25” OAL

Designed for use with standard 48” pallets and other common skids and containers. Forks can achieve a maximum elevation of over 7.5” and are shaped at the load wheel housings for pallet entry and exit without need for wearable rollers.

SERVICEABILITY

Removable covers and modular design of components provides for easy maintenance with simple hand tools. Two-piece drive wheel reduces

complexity of tire changes.
